T441 WS Hanger Packer

Operation:

The T441 Hanger Packer is a comprression set liner hanger packer for use in open hole or casing. The T441 WS Hanger uses deep wide wicker slips that penetrate in scaly casing and open hole formations. The WS Hanger cone is shear pinned to

eliminate premature setting of the packing element while running, once the slips engage the cone the brass shear screws break energizing the packing element. The T441 WS Hanger Packer is run in using the WS Running Tool. The running tool

comes with a two foot stroke allowing rotation at the hanger without picking up on the casing string, this allows the right hand break thread to rotate free and diconnect without damage.
